2.8" ILI9341 SPI Touch LCD Display

0 Comment
SKU:9PWWQ7VB58
Stock:10
$ 11.00
More:Arduino Shields
Contact
The 2.8'' ILI9341 Touch LCD Display SPI 240x320 is a full-color screen with a resolution of 240×320 pixels or 320×240 pixels, depending on orientation. It uses the ILI9341 controller with SPI interface and also includes a resistive touchscreen with built-in XPT2046 controller.

  • 2.8-inch color display, 16-bit RGB, 65K colors, displays rich colors
  • 320×240 resolution
  • Touch function support
  • Supports SD card function expansion

Technical Specifications
  • Power: +3.3 / 5 VDC
  • Current: <100 mA
  • Display Type: 2.8" TFT color LCD
  • Colors: 65K
  • Resolution: 240 × 320 pixels
  • Viewing Angle: 12 o’clock
  • Operating Temperature: -20 °C ~ +60 °C
  • Storage Temperature: -30 °C ~ +70 °C
