Sigma Basic Level Line Following Robot Kit 2000RPM

The open-source program is provided free of charge with this robot kit.

This robot kit is an unrivaled solution featuring 2000RPM motors, 8 sensors, and PID-controlled software.

With the ÇizgiZade V2 Arduino Robot Board, this robot kit becomes faster and fully professional. Thanks to the high-current, powerful MOSFETs that support the motor driving capability of the ÇizgiZade V2 Robot Control Board, it delivers 6 Amps continuous and 8 Amps peak power per channel, offering a unique track experience across 2 channels.

Note: We strongly recommend purchasing spare motors with the product. Since maximum voltage is applied to the motors, you should always keep spare motors on hand to prevent issues in case of malfunction.

To ensure that the center of gravity—an important factor in line following robots—is close to the ground and to provide better wheel traction, the robot’s motors and battery are positioned at the rear of the chassis. Additionally, specially manufactured Silicone Wheels, which are the secret behind all successful line following robots, are used in this kit, providing more stable road grip.

Since the motor mounting brackets are made of metal, there is absolutely no vibration in the motors. If your robot’s motors are fixed with plastic brackets and there is any wobbling, this may unfortunately lead to poor performance in competitions.

You can purchase our robot kit either disassembled or pre-assembled. The advanced software is provided free of charge with the kit, allowing you to achieve better results in robot competitions.

All spare parts of the Robot Kit are continuously kept in stock. We guarantee full support before and after sales with our technical support team.

Sigma Line Following Robot Kit – Material List

1 x ÇizgiZade V2 Arduino Robot Board
1 x Arduino Nano + USB Cable
1 x QTR-8A Infrared Sensor – Analog
2 x L Type Geared 6–12V 2000RPM Plastic Gear DC Motor
2 x Silicone Rubber Wheel (Diameter: 61mm – Width: 25mm)
2 x Plastic Caster Wheel
1 x Sigma Line Following Robot Chassis
1 x 11.1V 3S LiPo Battery
1 x LiPo Battery JST Connector
1 x USB Cable
10 x Female-to-Female Jumper Wire Set
2 x Metal Motor Mounting Bracket
1 x Screw Set for Assembly
1 x MZ80 Object Sensor – 80cm Range Infrared Sensor
1 x MZ80 Infrared Sensor Mount – Sensor Holder

Sigma Basic Level Line Following Robot Kit 2000RPM
