Especially suitable for Mini Sumo Robot Projects!
You can supply 12V to achieve higher torque and speed. The motor’s stall torque is 6.5kg/cm, making it a truly high-torque motor model. We strongly recommend applying higher voltage to this 6V motor.
It can be used not only for robot projects, but also for all kinds of projects that require torque and speed.
These geared motors, which have become popular in recent years, are successfully used in many industries thanks to their lightweight structure and compact size.
You can confidently use them in professional Mini Sumo Robots, industrial applications, and machinery.
Product Specifications:
- Operating Voltage Range: 6–12V
- Motor Speed: 550RPM (6V)
- Rated Load Torque: 1.50kg/cm
- Stall Torque: 6.50kg/cm
- No-Load Current: 275mA
- Stall Current: 4.2A
- Gearbox Diameter: 20mm
- Motor Diameter: 20mm
- Total Length: 49.80mm (maximum limit size for Mini Sumo)
- Shaft Diameter: 4mm (D-shaft)
- Shaft Length: 4.20mm (shaft is quite short)
- Weight: 53g
