TB6560 3A CNC Router 1 Axis Driver Board Stepper Motor Drivers
Using the Toshiba TB6560AHQ new original chip with low voltage shutdown, overheating stop and over current protection circuit to ensure optimal performance.
For two-phase within 42, 57 stepping 3A / four-phase / of line four / six-wire stepper motor, and is not suitable for more than 3A stepper motor.
Automatic half current function.
6N137 high-speed optical coupling, guarantee high speed without losing step.
Specification:
- Size: 75 x 50 x 35mm / 2.95 x 1.96 x 1.37inch (L x W x H)
- Rated maximum output: ± 3A, peak 3.5A
- Working voltage: DC 10V-35V
- Recommended to use a switching power supply: DC24V power supply
- Subdivision: whole step, half-step, step 1/8, 1/16 step, a maximum of 16 Subdivisions.
Package included:
- 1 x TB6560 1 axis driver board
