ENC28J60 Ethernet LAN Module

0 Comment
Brand/Manufacturer:Sumozade
SKU:511
Stock:Out of stock
₺ 239.20
More:Modules
Contact
ENC28J60 ethernet LAN modul is a converter board from ethernet input to SPI serial interface contains an ethernet connector. You may add internet connection advantages to your Arduino and other systems or projects with the Microchip ENC28J60 enthernet chip on the board. The biggest advantages of the modul is to have very small dimensions adn SPI serial interface, this makes life easier.

Features:

  • ENC28J60 independent ethernet modul with SPI serial interface
  • HanRun HR911105A ethernet connector
  • SPI serial interface
  • 3.3 V supply voltage
  • PCB dimensions: 51 mm x 19 mm

Documents:

Click here for example Arduino project.

Click here for the Arduino Ethernet library.

Click here for Arduino UIP ethernet library.

Click here for END28J60 datasheet.
